dsh-artifact

English · 简体中文

Render interactive ECharts / Mermaid / Three.js and sandboxed custom HTML inline in DeepSeek Harness conversations.

dsh-artifact lets the model render real, interactive content — not hand-drawn SVG, not a wall of text — directly inside the conversation. The model calls render_artifact with a declarative payload — a plain-JSON ECharts option, a Mermaid diagram, or a Three.js 3D scene — and the Web UI renders it with the real engine (tooltip, zoom, legend, diagrams, 3D previews). A second tool, render_html, renders arbitrary custom HTML/CSS/JS in a sandboxed iframe.

Why dsh-artifact

	dsh-genui	dsh-visualize	dsh-artifact
Model output	whitelisted JSON tree	arbitrary HTML/JS	declarative payload (ECharts / Mermaid / Three)
Real engine	✗ (3 hand-drawn chart kinds)	✓ (via HTML)	✓ (ECharts + Mermaid + Three.js)
Inline in conversation	✓	✗ (tool row only)	✓ (tool card)
Interactive	✓	partial	✓ (tooltip / zoom / legend / 3D)
Arbitrary HTML sandbox	✗	✓	✓ (render_html)
Action round-trip	✓	✗	roadmap (v0.3)
Security model	whitelist	sandboxed iframe	pure JSON + sandboxed iframe

dsh-genui hand-draws three chart kinds; dsh-visualize renders arbitrary HTML but has no round-trip. dsh-artifact feeds the real engines (ECharts, Mermaid, Three.js) with declarative JSON payloads the model is already excellent at writing, and adds a sandboxed HTML channel for custom widgets — full capability at a lower authoring cost, behind strict JSON-only and iframe-sandbox security boundaries.

Install

# From GitHub (recommended — ships prebuilt assets, no build step)
dsh plugin --profile web add github:sumarilkkxx/dsh-artifact

# Local link (development)
dsh plugin --profile web add link:/path/to/dsh-artifact

# From the project directory
dsh plugin --profile web add .

Restart dsh web and hard-refresh the page (Cmd/Ctrl+Shift+R).

Requires pnpm on PATH (the dsh plugin command forwards to pnpm).

Usage

Ask the model for a chart:

Draw a bar chart of 2024 quarterly revenue: 120, 180, 150, 210 (in 10k CNY)

The model calls render_artifact with an ECharts option, and the chart appears as an interactive card in the conversation.

render_artifact (charts / diagrams / 3D)

Parameter	Type	Description
engine	string	echarts (default) · mermaid · three
option	object / string	ECharts option — engine=echarts (plain JSON, no functions; string templates like {c}%)
code	string	Mermaid diagram source — engine=mermaid (flowchart / sequenceDiagram / classDiagram / gantt / stateDiagram / pie / erDiagram / journey)
spec	object / string	Three.js scene — engine=three ({"meshes":[{shape,color,size,position,rotation}],"background","ambient"})
title	string	Card title
height	number	Height in px (default 360, min 120)

render_html (sandboxed custom widget)

Parameter	Type	Description
html	string	Self-contained HTML fragment or full document (inline scripts/styles allowed; external resources blocked)
title	string	Card title
height	number	Height in px (default 400, min 120)

Example the model produces:

{
  "engine": "echarts",
  "title": "2024 quarterly revenue",
  "option": {
    "title":  { "text": "Revenue (10k CNY)", "left": "center" },
    "tooltip": { "trigger": "axis" },
    "xAxis":   { "type": "category", "name": "Quarter", "data": ["Q1", "Q2", "Q3", "Q4"] },
    "yAxis":   { "type": "value", "name": "Revenue" },
    "series":  [{ "type": "bar", "name": "Revenue", "data": [120, 180, 150, 210] }]
  }
}

Security model

• Declarative payloads (option / spec) must be pure JSON — functions, undefined, and symbols are rejected by the host half.
• Engine assets are served only from the plugin's own route; path traversal is blocked.
• render_html widgets run in a sandboxed iframe (opaque origin) with a CSP that blocks network, top navigation, and form submission; only inline scripts/styles are allowed.

How it works

dsh-artifact/
├── index.js               # host half: render_artifact + render_html tools + asset route
├── client.js              # browser half: keyed toolviews + engine dispatch + sandboxed iframe
├── cordis.patch.yml       # bundle layer (insert dsh-artifact)
├── package.json           # dsh.bundle + dsh.client manifests
├── assets/                # engine UMDs (echarts/mermaid/three; built, shipped for git-install)
└── scripts/build.mjs      # copies engine dists -> assets/

1. Host half (index.js) registers render_artifact and render_html as raw JSON-Schema definitions, injects system-prompt guidance, and serves the engine assets from /plugins/dsh-artifact/assets/*.
2. Browser half (client.js) registers keyed tool.call.toolview slots for both tools. When a result settles, the host projects the resolved payload into the result meta (via presentationMeta); the toolview dispatches on meta.engine and lazy-loads the matching engine. render_html renders into a sandboxed iframe with a CSP.
3. Zero @deepseek-ai/* runtime dependencies — both halves are hand-written plain JS. The host uses only Node builtins; the browser half takes react from the loader's module table. This deliberately avoids the developer-preview version-drift trap (the stale latest tag on @deepseek-ai/dsh-tools, and cross-package rc-line mismatches).

Development

Prerequisites

• Node.js >= 22.19
• pnpm on PATH (required by dsh plugin add)
• git

Project layout

Path	Purpose
index.js	Host half — render_artifact + render_html tool definitions, system-prompt section, lazy-asset route
client.js	Browser half — keyed toolviews, engine dispatch (echarts/mermaid/three), sandboxed iframe
cordis.patch.yml	Bundle layer; name is a package name resolved through node_modules, not a path
package.json	dsh.bundle + dsh.client manifests, exports["./client"], build scripts
assets/*.min.js	Engine UMD builds (echarts/mermaid/three; committed so dsh plugin add github:... needs no build)
scripts/build.mjs	Copies engine dists → assets/

Build

npm install     # installs echarts/mermaid/three (build-time only; NOT runtime deps)
npm run build   # copies the engine UMD bundles into assets/

The engines are devDependencies used only to produce assets/*.min.js. The plugin itself has zero runtime dependencies, so a link: install needs nothing extra. Bump an engine by editing its devDependency version and re-running npm run build.

Local debug loop

# from the project directory
dsh plugin --profile web add .

# restart dsh web + hard-refresh the page

The host and browser halves are plain files the profile reads directly, so code edits need only a restart (no build step). Rebuild only when you change the engine asset.

Verification

# compose-check: confirms the bundle layer parses and composes
dsh --profile <name> --dump-config

# local smoke test (not shipped in the repo)
node scripts/smoke-test.mjs

# browser render check: load the profile, confirm zero console errors and a painted canvas
# (see the acceptance flow used during development)

Design notes

• Raw tool definition. render_artifact is registered as a plain JSON-Schema object (not defineTool) because out-of-tree resolution of @deepseek-ai/dsh-tools is unreliable on the developer-preview line. The host half owns its own validation.
• Optional service via ctx.inject. The asset route uses ctx.inject(['webServer'], cb) so the plugin stays inert under headless profiles (no webServer service).
• Replay-safe presentation. The chart option travels to the browser through the tool result's meta (presentationMeta), which must stay pure (no file I/O) so session replay can rebuild the card.

Roadmap

v0.1 — ECharts tool channel ✅ shipped

• render_artifact tool (raw JSON-Schema definition, function-free option validation)
• Real ECharts engine, lazy-loaded from a self-hosted /plugins/dsh-artifact/assets/* route
• Keyed tool.call.toolview browser slot
• Pure-JSON security boundary (function/undefined/symbol rejection + path-traversal guard)
• Verified end-to-end: real model call → tool → result meta → browser canvas

v0.2 — multi-engine + HTML sandbox ✅ shipped

• Additional engines: mermaid (flow/sequence/class/gantt/state/pie/er/journey), three.js (declarative 3D scenes)
• A second tool (render_html): render model-written HTML/CSS/JS in a sandboxed iframe (opaque origin + CSP) for custom widgets the declarative engines cannot express
• Engine asset bundling generalized (per-engine UMD assets + a shared lazy loader)
• Verified end-to-end: all three engines render in a real browser; the sandbox runs inline scripts while blocking network

v0.3 — action round-trip (planned)

• postMessage-based [genui-action] loop: interactive components send data back to the model, which re-renders — the capability dsh-visualize explicitly lacks
• Local-first interactions (tabs, selection, local grading) with zero model round-trip

Later / ideas

• Real icon system (SVG icon library, not emoji)
• Native live data binding — bind components to host state (token usage, git status, subagent/job progress) without a model round-trip
• More engines: katex (formulas), leaflet (maps), frappe-gantt (timelines)
• npm publish + awesome-dsh-plugin listing

Contributing

PRs welcome. Please keep the host and browser halves free of @deepseek-ai/* runtime imports, and ship any engine change as a committed assets/ artifact (or update scripts/build.mjs). Add the dsh-plugin GitHub topic to help others discover the plugin.

License

MIT
