phone-tunnel-pool — Cloudflare quick-tunnel pool for the dsh web GUI

English | 简体中文

Enable/disable a self-healing Cloudflare quick-tunnel pool for http://127.0.0.1:3080 (the DeepSeek Harness web GUI) from a floating widget with a scannable QR code. One scan from your phone, and the pool keeps itself alive:

• Generational rotation (12h): a new pair of tunnels spawns on schedule; older generations stay alive while anything is still on them.
• Chase service worker: every origin your browser touches registers a service worker. Dead or rotated hostnames redirect to a live sibling or the newest primary — the same open tab survives generation changes as long as it stays connected.
• Prompt-free migrations: the proxy injects credentials only into pages it has already authenticated; before any redirect the watchdog pre-authenticates the target hostname (minting its auth cookie), so migrations land authenticated — no "Authentication required" popups.
• Usage-based retirement: generations retire only when idle (no tabs / websockets / recent traffic) or at a hard age cap.
• Respawn with backoff: dead tunnels are replaced with new hostnames; quick-tunnel mint quota (Cloudflare 429) is respected via exponential backoff + a 2-probe dead-grace (DNS propagation).

Extra: the daemon runs detached and adopts across dsh web restarts, so the same URL, password and QR stay valid until you click Disable — no re-scan (an OS reboot still costs one fresh scan; a named tunnel removes even that — see PLAN.md §7).

Install / Uninstall

# install (from this public repo)
dsh plugin --profile web add github:iimaguest/phone-tunnel-pool
dsh web        # the GUI shows a floating 📱 widget (bottom-right)

# uninstall (one command — removes the dependency AND the dsh.profile.bundles layer)
dsh plugin --profile web remove phone-tunnel-pool
dsh web

After install: open the widget → Enable → scan the QR with your phone camera. Install/remove reconcile dsh.profile.bundles against the installed state automatically — never edit ~/.dsh/profiles/web/package.json by hand; a stray bundle entry with no matching dependency is exactly the kind of state that fails profile boot ("cannot resolve profile bundle").

Prerequisites (all of them)

What	Needed?	Who provides it
dsh web running on its default port 3080 (DSH_TARGET_PORT to override)	required	you (the plugin tunnels to it)
cloudflared binary on PATH	required	you — brew install cloudflared (or apt/dnf/Chocolatey, or set DSH_CLOUDFLARED to the existing binary)
Node.js runtime	required	dsh itself — no separate install (the daemon reuses dsh's node)
python3 + qrcode package	optional	you — pip install qrcode; without it the widget shows URL + login instead of a scannable QR
caffeinate	optional	macOS ships it; skipped elsewhere
PowerShell	optional	Windows ships it — used only for process cleanup on Windows (no pkill there)
Outbound network	required	cloudflared → Cloudflare edge on 443/7844 (no inbound port needed)

The widget preflights these on dsh web start and shows a yellow warning line (with the exact fix, e.g. brew install cloudflared) before you even click Enable; the daemon also fails fast with a readable error if cloudflared is missing at Enable time, and refresh in the popup re-checks everything — a stale error clears once the prereqs pass.

The feature flag set is version-gated on cloudflared --version: 2024.6+ enables the opt-in post-quantum handshake (DSH_PQ=1), 2024.8+ adds --management-diagnostics=false; older builds (apt/dnf packages) get a reduced, compatible flag set.

Platforms. macOS, Linux and Windows (Windows uses PowerShell for process cleanup; caffeinate is macOS-only and silently skipped elsewhere). The daemon's state file and log live in the per-OS temp directory (os.tmpdir()); the widget settings file (iptunnel-settings.json) lives in ~/.dsh.

Screenshots

Live hostnames, credentials and the QR are blurred out in these shots.

How it's wired

dsh web GUI  <--  /iptunnel routes  --  auth proxy (127.0.0.1:3090)
                                              │  Basic + session cookie,
                                              │  Host rewrite to 127.0.0.1:3080
                                              │  (the GUI's browser-trust fence)
                                              ▼
cloudflared A ─ to ─ auth proxy ───────────────────────────────────┐
cloudflared B ─ to ─ auth proxy ───────────────────────────────────┤ (tunnel daemon
    ... new generations ...  ──────────────────────────────────   │   manages all)

Files: lib/index.js (host API: enable/disable/adopt, state + QR SVG routes), lib/daemon.mjs (detached pool brain: spawn, probe, rotate, retire, respawn), cf-auth-proxy.mjs (public /iptunnel/* service paths + Basic auth + watchdog injection + credential handoff), iptunnel-sw.js (chase service worker), iptunnel-watchdog.js (open-tab watchdog), lib/client.js (widget), verify.sh (end-to-end audit). PLAN.md = full spec + edge cases; NOTES.md = engineering history.

Resource footprint (minimal by default)

• Disabled = zero processes (just the floating pill in the GUI).
• Enabled = 1 node daemon + 1 auth proxy + 2 cloudflared per live generation. Default ceiling: 4 generations × 2 = 8 tunnels (a busy pool runs all of them; idle generations retire on their own after 60 min).
• Knobs to shrink further: DSH_MAX_GENS=2 (≤4 tunnels), DSH_IDLE_MS=1200000 (retire after 20 min idle), DSH_PQ — post-quantum handshake is opt-in (DSH_PQ=1) because it costs CPU per connection; without it the tunnel uses the classic handshake.
• Phone battery: the watchdog backs off 30s → 300s (5 min) while nothing changes.
• Keep-awake is opt-in: caffeinate (macOS) is off by default; turn it on in the widget ("Keep machine awake while enabled") or via DSH_CAFFEINATE=1 — it applies on the next Enable (and lets the display sleep — -i only, no screen-on drain). Without it, an idle MacBook may sleep and the pool goes quiet until it wakes.
• Daemon log is capped at 512 KB (keeps the last 128 KB); probes run at 30s.

Security model

• The password is generated per Enable, held in memory, shown in the widget and embedded in the QR; nothing is committed or published. (The daemon keeps the current credentials in a 0600 state file under the OS temp dir so the tunnel survives a dsh web restart; that file is deleted on disable.)
• /iptunnel/* service paths (health, sw-config, sw.js, entry, watchdog.js, telemetry, preauth) are public by necessity — browsers fetch service workers without credentials; they carry hostnames and pool liveness only. The credential handoff (/iptunnel/preauth) mints a cookie only for a caller presenting the valid password; it never echoes anything.
• window.__ptAuth is injected only into HTML the proxy has authenticated.
• The proxy listens on 127.0.0.1; public network exposure happens only through the tunnel hostnames — the QR/hostname is a bearer secret (anyone who gets it can open the tunnel while enabled): disable when done.
• Quick tunnels are testing-grade (no uptime SLA, per-IP mint quota). The repo-agnostic sibling package carries the same pattern for any local port; a named tunnel is the lifetime endgame (one stable hostname → no re-scans, no prompts, no quota).

License

Apache-2.0 — see LICENSE. Third-party code: cloudflared (distributed by Cloudflare), the Python qrcode library — used at runtime, not vendored.
