dsh-rev-eng

One DeepSeek Harness plugin, two skill packs: REA 6.8.0 for understanding shipped apps, binaries, and bundles, and BAMA 1.0.0 for taking a native macOS app from idea to Dock. 23 skills total (21 BAMA + 1 REA + the rev-eng router) ride with every profile that installs the bundle, and the optional REA MCP server adds 229 analysis tools for sessions that need them.

Requires DeepSeek Harness >=0.2.1-rc.3 <0.3.0-0 and Node.js >= 22.

_{Real /rev-eng session: the prompt and the model answer are verbatim, only the typing is animated. Transcript · asciinema recording}

What you get

Reverse engineering with REA

REA explains how a shipped feature works from the artifact itself: native binaries, Electron and JavaScript bundles, Android packages, firmware, GPU code objects, .NET assemblies, packaged apps, and runtime captures. The skill routes the target, gathers evidence, and reports what it can and cannot establish.

• reverse-engineer-anything is the workflow skill. It ships with seven reference guides covering target handling, evidence workflows, environments, runtime observation, Android, JavaScript, and native artifacts, plus a dsh-specific guide for the optional MCP mount.
• The optional REA MCP server exposes 229 tools to the session as mcp__rea__*, for interactive binary and application analysis.
• Analysis engines are optional and separate: Hopper, Ghidra, or IDA for native code, JADX plus a JDK for Android, Binwalk or Unblob for firmware on Linux. Static JavaScript and .NET inspection need no native engine.

Native Mac apps with BAMA

BAMA is a pipeline of 21 skills that turns a screenshot, spec, or idea into a Swift 6 / SwiftUI app: research, clone, brief, user stories, scaffold, code, macOS integrations, design, performance, tests, and shipping. Specs for 12 small apps (window snapper, launcher, clipboard history, screen recorder, and more) ship as examples under skills/app-brief/specs/.

Start here

The user wants to	Skill
Pick the next step in the pipeline	bama (type /bama)
Route between reverse engineering and Mac-app work	rev-eng (type /rev-eng)
Understand a shipped app or binary	reverse-engineer-anything

Build with BAMA, by stage

Stage	Skill	What it does
Start	bama	Router: finds where you are and calls the right skill
Start	app-brief	Turns an idea (or an example spec) into a one-page brief
Start	new-mac-app	A working app from a template: Swift package, SwiftData, build script, snapshot mode, git
Plan	research	Market, users, features, design, and macOS API research
Plan	clone	Screenshots every screen of an app, with computer use or a browser
Plan	user-stories	A backlog with checkable acceptance criteria, in milestones
Code	swift-swiftui	Swift 6 concurrency, state, SwiftData, AppKit bridges, compiler errors
Code	os-integrations	Hotkeys, menu bar, floating panels, window control, screen capture, Shortcuts, URL schemes, permissions
Code	performance	Measure first, then fix: main thread, GPU compositing, images, Instruments
Code	improve-architecture	Finds hot spots and refactors one step per commit, with behavior proven unchanged
Code	agent-cli	Optional CLI and MCP server so agents and scripts can drive the app
Design	ux-design	Names, flow, where each feature opens, words, accessibility, before code
Design	mac-design	Liquid Glass, layout, toolbars, menus, keyboard, type, dark mode
Design	design-system	An accent color and one set of tokens with a rules page
Design	layout-grid	A 4 pt grid with checks that fail on misalignment
Design	design-kit	Your own parts, tokens, type, icon set, window chrome, and parts gallery
Design	design-from-app	Rebuilds the look of an app from screenshots, compared pixel by pixel
Design	app-icon	A Liquid Glass icon, checked in every look
Ship	build-and-verify	Build, install, snapshot every page in light and dark, look at them
Ship	test-mac-app	Swift Testing, an in-app self-test, a debug bridge an agent can drive
Ship	improve-loop	Works through the backlog one story per commit until a milestone is done

bama is user-invoked: type /bama to start the pipeline. rev-eng is the pack router and is model-invocable as well, so the agent can reach it on its own.

Requirements

• DeepSeek Harness >=0.2.1-rc.3 <0.3.0-0, desktop app or CLI. The Plugins UI checks the package's bundle patch and engines.dsh compatibility before installing.
• Node.js >= 22 for the plugin itself.
• macOS 26 or later and the Xcode 26 toolchain (Swift 6.2) for BAMA builds. You never need to open the Xcode app, but swift, xcodebuild, sips, and xcode-select must be available. xcode-select --install covers the command line tools.
• Computer use (optional) for visual verification: BAMA's clone and verify steps use the harness computer-use capability when the session has it, and otherwise ask you for screenshots.
• Node.js and npm for REA. REA's MCP server and CLI run on Node 22 and later; its setup command additionally requires ^22.23.4, ^24.22.1, or >=26.12.1. Network access is needed for the first npx rea-agents run.
• Optional REA engines: Hopper, Ghidra, or IDA for native analysis; JADX plus a JDK for Android; Binwalk or Unblob for firmware on Linux. The skill never installs engines on its own: installing one is a separate, user-approved step.
• Windows: the skills install fine with scripts/install.ps1, and REA's analysis paths are not macOS-only, but BAMA builds native Mac apps and requires macOS. The shell installer needs Git Bash or a POSIX shell.

Install

Two channels: install the bundle into a dsh profile, or copy the skill directories into a skill root. Use one channel. Do not do both: the two copies claim the same skill names, and the duplicate resolution depends on provider order rather than on which copy you meant to use.

Option 1: install the bundle (recommended)

The bundle carries its skills inside the package, so a single profile install gives the whole pack to every session on that profile. dsh forwards the command to pnpm, so a local path, an npm package, or a Git spec all work:

# from a checkout (installs as a link: dependency; the checkout must stay in place)
dsh plugin --profile web add /absolute/path/to/dsh-rev-eng

# from npm
dsh plugin --profile web add dsh-rev-eng

# from git
dsh plugin --profile web add github:Stijnus/dsh-rev-eng

Install into an existing app profile (web, tui, or headless), not an arbitrary new name: a profile created only by dsh plugin add contains the base runtime but no app bundle, so it cannot boot. Confirm the layer composed, then boot the profile:

dsh --profile web --dump-config   # contains "# == dsh-rev-eng" and "- id: rev-eng-skills"
dsh --profile web

Desktop app. The desktop profile is managed exclusively by the app, and ordinary CLI boot or --dump-config of it is refused. Install from the app's Plugins → Add plugin dialog instead: it accepts a package name with an optional version (dsh-rev-eng), a Git address, a tarball, or the absolute path of a local checkout. It inspects the spec first (package manifest, bundle patch, and engines.dsh / peer compatibility), then runs the profile's package install and offers Enable now. This is the same inspect → package-install → enable operation the CLI performs, scoped to the running desktop profile. Uninstall from the bundle's page there. Do not run dsh plugin --profile desktop from a terminal: the desktop profile belongs to the app, and the Plugins page is the supported install path.

A local-path install is saved as a link: dependency, so the checkout must stay where it is. For distribution to other machines, publish a new version, push a Git tag, or upload a tarball and install that spec through the CLI or the Plugins page.

Option 2: drop-in skill copy (no bundle)

For a quick no-install trial, copy the packaged skills into a skill root that dsh already watches. This works across profiles and needs no package install:

# macOS / Linux / Git Bash: into ~/.dsh/skills (DSH_HOME is honored)
bash scripts/install.sh

# Windows PowerShell: same target
powershell -ExecutionPolicy Bypass -File scripts\install.ps1

Flags:

bash scripts/install.sh --list                 # shipped skill names + the target roots
bash scripts/install.sh --project ~/code/my-app # <project>/.dsh/skills, rank 100
bash scripts/install.sh --user-agents          # $DSH_AGENTS_HOME/skills (~/.agents/skills), rank 500
bash scripts/install.sh --uninstall            # remove this pack's skills from the selected target

--uninstall removes only the pack's known skill directories; everything else in the directory is left untouched. --project requires the directory to exist. The PowerShell script takes -Project, -UserAgents, -List, and -Uninstall.

The drop-in copy is picked up by the skill-root watcher without an app restart, and a new session is the cleanest way to confirm it. What the installer does: it copies each skills/<name>/ directory as-is (references, scripts, templates, and example specs included), preserves the scripts' executable bits, replaces a previous copy of the same skill directory on a re-run, and prints the target and the next steps.

There is no one-shot bundle trial. Booting with --patch cordis.patch.yml composes the layer but the plugin cannot import until the package is installed into the profile (Cannot find package 'dsh-rev-eng'), so the harness starts without the skills. Use the drop-in copy for a no-install trial.

Optional: REA MCP server

Installing this pack gives the agent REA's workflow instructions, not REA's tools. The MCP server is an explicit opt-in for reverse-engineering sessions. REA 6.8.0 officially supports dsh, so REA can write the registration itself; the package also ships an overlay for environments where that setup flow should not run.

Official registration (REA writes the row)

Review the read-only plan, then apply it:

npx -y rea-agents@6.8.0 setup --client dsh --skill=false --dry-run --json
npx -y rea-agents@6.8.0 setup --client dsh --skill=false --yes

Setup writes one row with id rea-mcp, serverName rea, and the @deepseek-ai/dsh-mcp-client module into $DSH_HOME/cordis.patch.yml. That is the home patch: it applies to every profile on the machine, the desktop app included. Setup preserves unrelated patches and comments and replaces only its own launcher fields. After it runs, restart dsh (quit and reopen the app, or exit and relaunch the CLI profile), then verify that mcp__rea__* tools appear in a session.

--skill=false is the correct choice when this pack is installed. The pack's provider exposes the adapted REA workflow skill at rank 400; the canonical copy setup would install lands in ~/.agents/skills ($DSH_AGENTS_HOME/skills when set) at rank 500, where the same skill name is shadowed, so installing it would only add a redundant duplicate. (The pack's provider wins on rank. Without this pack, rea setup --skill is the canonical install.)

Inspect the registration with rea doctor --client dsh --json; a healthy, aligned result appears once the row exists. rea uninstall removes the REA row and any REA-installed skill.

Node version gate. REA 6.8.0's setup hard-gates Node: it accepts ^22.23.4, ^24.22.1, or >=26.12.1, and refuses other releases. The MCP server itself runs fine on the refused versions, so only setup is blocked. Options when the plan reports the gate:

• Upgrade Node to an accepted release and rerun setup.
• Run the same REA setup under an accepted runtime, pointing npx -y node@24.22.1 at the installed rea-agents/scripts/rea.mjs entry point.
• Skip setup and use the pack overlay below, which needs no rea setup and has no Node gate.

Pack overlay (no setup)

patches/rea-mcp.yml is one insert row with the same id and serverName, an npx -y rea-agents@6.8.0 mcp launcher, and toolCallTimeoutMs: 600000. One-shot use, for a single run of a profile:

dsh --profile web --patch /absolute/path/to/dsh-rev-eng/patches/rea-mcp.yml

For permanent use, merge the single insert row into a profile patch ($DSH_HOME/profiles/<name>/cordis.patch.yml) or into the home patch ($DSH_HOME/cordis.patch.yml), then restart dsh. Merge, do not replace: the file may hold unrelated patches.

Never enable the official registration and the overlay together. Both use serverName: rea, and dsh refuses two MCP entries with the same server name even when they sit in different layers. The result is a duplicate-server-name load failure with missing tools. Use one, not both.

What to expect from the mount

• Tools appear to the model as mcp__rea__<rawName>, for example mcp__rea__open_binary. The guides use REA's raw names; add the prefix when calling.
• Timeout: dsh sets one toolCallTimeoutMs per row, default 60000 ms, which is far too short for real analyses. The overlay sets 600000 ms; the official row has no timeout by default, so add toolCallTimeoutMs: 600000 under its config (REA keeps caller-owned config fields when it later rewrites its own row). REA's own static-analysis budget defaults to 300000 ms, and a cold native provider import can take longer.
• Context cost: 229 tools enter the model's tool list while the row is active. Enable the mount for reverse-engineering sessions rather than as a permanent global default when context budget matters.
• Connection behavior: a row that cannot start does not abort the harness. The session starts without the REA tools and the client logs mcp-client(rea) lines. The first npx start also pays a package download (seconds, not minutes) when the npm cache is cold; a warm cache connects in under a second.

Use it

Prompts pick the pack through the rev-eng router, then the skill does the work. A few examples:

You say	What loads
"Explain how the Notes app renders search results, down to the binary, and show me the evidence."	rev-eng → reverse-engineer-anything (native analysis; an engine is needed)
"Inspect this Electron app's app.asar, list its IPC channels, and compare them with the previous release."	rev-eng → reverse-engineer-anything (static JavaScript, no native engine)
"Rebuild the look of this app as a native Mac app."	rev-eng → reverse-engineer-anything for evidence, then BAMA's clone
"Write a one-page brief for a menu bar clipboard manager."	bama → app-brief
"Build the window-snapper spec, then snapshot every screen and run the tests."	bama → app-brief → user-stories → new-mac-app → build-and-verify

You can skip the router and ask for a skill by name, or type /bama or /rev-eng to start one directly. One skill loads at a time; each skill tells the agent which skill comes next.

How it works

• The package is a dsh bundle: package.json points dsh.bundle.patch at cordis.patch.yml, which inserts the rev-eng-skills row named dsh-rev-eng into the profile's composition.
• That row mounts the plugin in src/index.js, which registers a skill provider over the packaged skills/ directory. The provider scans the directory on every list(), reads each SKILL.md with the flat frontmatter parser in src/frontmatter.js, and serves the bodies on demand with the skill directory as the resource base.
• The provider runs at rank 400 with source bundled. That beats a copy in ~/.agents/skills (rank 500), while project skill roots (ranks 100 to 200) and configured custom directories (rank 300) still win. A drop-in copy in ~/.dsh/skills is also rank 400, which is why the two install channels should not be combined.
• A provider is used instead of a customSkillDirs entry because the profile's composition base URL is the profile directory, not this package. Packaged skills have to ride with plugin code that resolves its own paths from import.meta.url, so the bundle works wherever the package is installed.
• The rev-eng router is packaged as a normal skill. bama keeps disable-model-invocation: true, so it is user-invoked with /bama; the other 22 skills are model-invocable.
• Live edits: the packaged provider rescans skills/ on every list but installs no file watcher, and the skill registry caches catalog snapshots. Editing an installed skill's body is visible on its next skill call; adding a new skill directory to an already-installed package needs a new session. The drop-in copy path uses dsh's watched local provider, so additions there appear without a restart.

Differences from upstream

The skills are the upstream workflows with dsh's tool names, path idioms, and client setup; technical substance, skill names, references, scripts, templates, and example specs are preserved. REA's client-specific connection guide was rewritten for dsh and a new dsh harness guide was added. BAMA's nested layout was flattened, cross-skill links were re-pointed, specs/ moved under the app-brief skill, and client-specific metadata directories were dropped.

The mapping table, the REA official-client handling, and the per-skill change log are in docs/adaptation.md. Detailed per-file logs are in the repository's notes/bama-adaptations.md and notes/rea-adaptations.md.

Troubleshooting

Skills are not listed

• Install the bundle into the profile you actually started, then start a new session on that profile. A session that started before the install does not pick up the bundle's catalog.
• A profile created by dsh plugin add alone has no app bundle to launch. Install into a shipped app profile (web, tui, headless) or into the desktop profile through the Plugins page.
• Check dsh --profile <name> --dump-config for the # == dsh-rev-eng layer. If the layer is missing, the package did not install into that profile.
• If you installed both the bundle and the drop-in copy, duplicate skill names resolve by provider order. Remove one channel.
• If you edited or added skill directories inside an installed package, restart the session: the packaged provider does not watch the filesystem.

REA MCP tools are missing

• Confirm a row exists: the home patch $DSH_HOME/cordis.patch.yml after official setup, a profile patch after a permanent overlay merge, or the --patch flag for a one-shot run.
• Restart dsh after any configuration change: the home and profile patch layers are composed at boot. A session that started before the row loaded never gains the tools.
• Run rea doctor --client dsh --json to inspect the registration from REA's side.
• Check for duplicate serverName: rea rows from enabling both the official setup and the overlay. Remove one row and restart.
• Make sure npx is on the harness's PATH: the row launches npx as a child process and inherits PATH but not credential-named or DSH_* variables. A cold npm cache makes the first connection slower; retry once before diagnosing.
• If calls fail while tools exist, the row probably hit toolCallTimeoutMs (default 60000 ms). Raise it, and note that a client-side timeout does not prove REA finished or released its analysis session.
• Approval prompts are the harness's, not REA's: the session's permission preset decides what is allowed. An unattended run reports the blocked operation instead of retrying it.
• When the row cannot start, look for mcp-client(rea) lines in the harness log: initial connection and discovery failures, reconnect attempts, and the final giving up ... tools unregistered line appear there. The fastest independent check is to launch the same profile from a terminal.

BAMA builds fail

• Verify the toolchain: xcode-select -p prints a developer directory, and swift --version reports Swift 6.2 or later. xcode-select --install installs the command line tools when they are missing.
• BAMA targets macOS 26 and later with the Xcode 26 toolchain. An older toolchain fails on the generated package before app code runs.
• Visual checks need the harness computer-use capability when the session has it; otherwise the skills fall back to asking you for screenshots. Say so explicitly when you cannot provide them.
• Windows: the skills can be installed, but the BAMA skills build native Mac apps and do not run on Windows.

Uninstall

• Bundle: uninstall dsh-rev-eng from the bundle's page in the Plugins UI, or run dsh plugin --profile <name> remove dsh-rev-eng for a CLI profile. On the desktop profile, use the Plugins page.
• Drop-in copy: bash scripts/install.sh --uninstall (add --project <dir> or --user-agents to pick the target you installed into). The PowerShell script accepts -Uninstall with the same target flags.
• REA MCP: after official setup, run rea uninstall to remove the row (and any REA-installed skill). An overlay row merged by hand is not REA's to remove: delete that insert from the patch file. A one-shot --patch run writes nothing permanent.
• No configuration is shared between the bundle and the drop-in copy, so uninstalling one does not affect the other.

Provenance and license

• PROVENANCE.md records the upstream repositories, pinned commits, licenses, and the refresh procedure.
• LICENSE is MIT: this package's adaptation plus the preserved upstream notices for REA (Copyright (c) 2026 morluto) and BAMA (Copyright (c) 2026 Dave Ebbelaar).
• CHANGELOG.md lists the 0.1.0 contents.

Responsible use

REA is a dual-use analysis toolkit. Target execution is real: runtime tools attach to processes and can change files, memory, and network state regardless of the harness sandbox around the client. Analyze only targets you are allowed to analyze, and keep the scope explicit. Read the upstream disclaimer before using REA.

Development

npm test                    # syntax checks + plugin unit tests
npm run lint:skills         # validate every SKILL.md, link, and frontmatter rule
./verification/verify.sh    # acceptance gate in an isolated DSH_HOME
./verification/verify.sh --full   # plus a live boot and REA MCP connection check
python3 scripts/make-demo-gif.py  # rebuild the README demo GIF and asciinema cast

The gate never touches your real dsh home or desktop profile. docs/adaptation.md explains how to re-sync from upstream, and verification/REPORT.md records the exact tested install story and known limits.
