🪶 dsh-lark-plus
DeepSeek Harness × 飞书/Lark 双向桥接
私聊 / 群聊 · 卡片按钮 · 审批与提问回传 · 任务板 · goal · 定时任务
外加:全程本机的语音转文字 + 网页端播放条
中文
DeepSeek Harness × 飞书/Lark 双向桥接插件:把 DSH 智能体装进飞书——扫码建应用、30 秒上线,在飞书里对话、点卡片、回审批、跑任务、看任务板。在此基础上还带了一条全程本机的语音链路:飞书里按住说话,音频在本机由 SenseVoice 转成文字,并可直接在 DSH 网页端回放——音频不出本机、不调任何云端语音 API。
本仓库是
dsh-lark-link的 fork(MIT,原作者及贡献者版权保留)。桥接部分沿用上游实现,语音链路为新增。详见文末归属与许可。
🌟 桥接能力(沿用上游)
- 零门槛:
/lark setup扫码即建飞书应用,不用手搓开放平台、不用配回调、不用公网服务器 - 零丢失:出站 Outbox + 入站 WAL 双持久化,进程崩溃 / 插件热更 / dsh 重启后消息与回答都补得回来
- 零学习成本:切换类命令都是单选卡片,点一下即生效;DSH 原生命令直接用
- 真 Agent:不是聊天机器人——bash / 文件 / 子代理 / 工作流全套工具,飞书里跑完整 Harness
✨ 特性
| 能力 | 说明 |
|---|---|
| 🎙 本地语音转写 | 飞书发语音 → 本机 SenseVoice 转文字(见上文);音频原文件始终保留 |
| 🎯 一键认证 | /lark setup 扫码创建飞书应用(自动订阅消息事件 + 群聊全量 + 表情权限 + 用户基本信息),30 秒上线;也支持 DSH_LARK_APP_ID/SECRET 手动通道 |
| 🧠 多模式 Agent | 标准 / PTC / 极简 / Cordis preset + 你在 GUI 自建的 preset,飞书发 /mode 出单选卡片即切 |
| 🎛 权限分级 | 只读 / 工作区写 / Full access 三种权限,/permission 卡片即切 |
| 🎨 卡片化命令 | /mode /permission /model 全是单选按钮卡片——点一下即切换 |
| 💬 意图确认转发 | 模型提问(ask_user_question)→ 飞书意图确认卡片,答完模型继续 |
| 😊 表情回执 | 收到消息随机表情;回复完成 / 命令完成打 DONE ✅ |
| 💪 出站零丢失 | 持久 Outbox(JSONL + at-least-once + 幂等键 + 分航道并行 + 周期清理) |
| 🆕 入站请求补发 | Agent 处理到一半插件/dsh 崩溃,重启后自动重新触发该消息 |
| 🛡 连接自愈 | probe 驱动受控重连 + 配额熔断 + 断连补偿;环境代理自动规避 |
| 🔀 命令三级分流 | 桥特有命令桥处理;DSH 注册命令原生执行;其余原样注入 Agent |
| 📎 入站多媒体 | 飞书图片 → 视觉模型看图;文件 → 有界文本提取;语音 → 本地转写 |
| 📤 出站多媒体 | 模型经 lark_plus_send_local_file 主动回传本地图片/文件 |
| 🩺 一键诊断 | /doctor → ZIP 诊断包(含当前会话 session log + 脱敏配置) |
| ✍️ Markdown 渲染 | 回复自动检测 markdown → CardKit 卡片渲染,纯文本走文本消息 |
| 🌊 可选流式输出 | /lark-config streaming.enabled=true 热开流式卡片(默认关,省流量) |
| 🖥 复用 DSH Web GUI | 桥 Agent = 原生 DSH session,聊天/工具卡/设置全由 GUI 呈现 |
| 👥 访问控制 | allowlist 白名单;groupPolicy 群聊触发策略;denyList 命令前缀拒绝兜底 |
🚀 快速开始
前置:Node.js ≥ 24,已安装 DeepSeek Harness。语音功能另需 ffmpeg(见上文)。
安装(DSH 官方 bundle 机制,产物已随仓库提交,不执行构建脚本):
# 从 npm 安装(推荐,已发布 0.1.0)
dsh plugin --profile <你的档> add dsh-lark-plus
# 从 GitHub 仓库安装(跟进尚未发版的提交用这条)
dsh plugin --profile <你的档> add github:AnFRuJ/dsh-lark-plus
# 或本地目录(源码开发时)
dsh plugin --profile <你的档> add link:/path/to/dsh-lark-plus
装完在 DSH 输入框执行一次扫码上线:
/lark setup # 手机飞书扫码,自动创建应用并写入凭据
/lark start # 建立长连接
/lark status # 查看连接/会话/补发计数
之后在飞书里直接发文字、图片、文件,或按住说话发语音。
桌面版 DSH 的
desktop档由 Electron 独占,CLI 会拒绝;那种情况请走 GUI 侧边栏「插件」页添加同一条地址。
🎙 附加能力:本地离线语音转文字(+ 网页端回放)
它是怎么工作的
飞书语音(OGG/Opus)
↓ 下载(本机 → 飞书 API,唯一的网络请求)
↓ 原文件落盘保留 ← 你随时能在飞书回听,agent 也能复读同一份文件
↓ ffmpeg 转 16 kHz 单声道 WAV
↓ SenseVoice(sherpa-onnx,CPU 推理)
文字 → 作为这条消息的正文交给智能体
- 引擎:SenseVoice(int8,中/英/日/韩/粤 + 自动标点),通过
sherpa-onnx-node在本机 CPU 上跑。 - 音频去向:只有一次联网 —— 下载约 228 MB 的模型。下载不在插件装载时触发(安装 / 激活 / 启动永远秒级):第一次收到语音消息、或在侧栏面板点「下载模型」、或调用
POST /dsh-voice-local/v1/model/download时才开始。之后完全离线。 - 失败不丢消息:模型没下好、ffmpeg 缺失、解码失败时,音频照样落盘,正文留空并把原因写进日志。同一条语音永远不会因为转写失败而消失。
- 可关:配置里
voice.enabled: false就只保留音频、不做转写。 - 可回放:DSH Web UI 里每条语音正文下面直接有一条播放条(宿主只读路由
GET /plugins/lark-plus/audio?name=…,支持 Range),不用回飞书重听;原始附件卡片会被隐藏,一屏只剩「文字 + 播放条」。
前置条件
| 依赖 | 说明 |
|---|---|
| ffmpeg | 必须。飞书语音是 OGG/Opus,模型只吃 16 kHz WAV。默认按 PATH 查找,也认 voice.ffmpegPath / DSH_VOICE_FFMPEG。 |
| 模型 | 装载时不会下载;首次需要转写时(或手动点「下载模型」/ 调 POST /dsh-voice-local/v1/model/download)才下到 $DSH_HOME/voice/sensevoice/(默认 ~/.dsh/voice/sensevoice/),与 dsh-voice-local 共用同一目录——装过那个插件、或已手动放置模型,都不会重复下载。可用 voice.sha256 / voice.modelSha256 / voice.tokensSha256 做完整性校验。 |
手动放置模型(内网 / 下载慢时):解压官方归档,保证目录里有 model.int8.onnx 和 tokens.txt 即可:
mkdir -p ~/.dsh/voice/sensevoice
# 官方:https://github.com/k2-fsa/sherpa-onnx/releases/download/asr-models/
# sherpa-onnx-sense-voice-zh-en-ja-ko-yue-int8-2024-07-17.tar.bz2
tar -xjf sherpa-onnx-sense-voice-zh-en-ja-ko-yue-int8-2024-07-17.tar.bz2 \
--strip-components=1 -C ~/.dsh/voice/sensevoice
配置
# cordis.patch.yml(profile 的 patch 层)
- id: lark-plus
config:
voice:
enabled: true
modelDir: '' # 空 = $DSH_HOME/voice/sensevoice
ffmpegPath: '' # 空 = 自动探测
modelUrl: '' # 主下载源覆盖
mirrors: '' # 逗号分隔,优先于内置镜像(hf-mirror / ghfast)
sha256: '' # 可选:模型归档 tar.bz2 的 SHA-256
modelSha256: '' # 可选:model.int8.onnx 的 SHA-256(直连文件源)
tokensSha256: '' # 可选:tokens.txt 的 SHA-256
timeoutMs: 600000 # 可选:单次下载尝试上限(默认 10 分钟);慢源失败即换下一个
ffmpegTimeoutMs: 60000
本地转写接口
语音链路把转写能力也开成了本机路由(可直接被其他工具复用;只服务本机):
| 方法 | 路径 | 说明 |
|---|---|---|
GET |
/dsh-voice-local/v1/health |
引擎 / 模型 / ffmpeg / 下载状态 |
GET |
/dsh-voice-local/v1/model/status |
模型文件与下载进度 |
POST |
/dsh-voice-local/v1/model/download |
触发后台模型下载 |
POST |
/dsh-voice-local/v1/transcribe |
body = 16 kHz 单声道 PCM16 WAV,返回 { ok, text } |
自测
npm run test:voice # 真实模型 + 真实 ffmpeg;资产缺失时自动 skip
npm run check # tsc --noEmit
📖 完整文档
下面保留上游的中文文档(命令、卡片、诊断、配置项等),其中的命令名已同步为 /lark。
⌨️ 命令
DSH 侧(GUI 或终端)
/lark setup 扫码一键建应用(或 DSH_LARK_APP_ID/SECRET 手动通道)
/lark start|stop|restart|status 桥接生命周期与全链路健康
/lark uninstall-clean 清除凭据与状态目录
飞书侧(卡片化单选,无需记忆拼写)
| 类别 | 命令 | 行为 |
|---|---|---|
| 选择类 | /mode /permission /model |
单选按钮卡片,点选即切换(动态感知自建 preset 与提供商) |
| 目标类 | /goal [目标|pause|resume|clear] |
启动长任务自主执行 / 暂停 / 恢复 / 清除当前目标 |
| 状态类 | /status /sessions /help |
全链路健康(含 Outbox/补发计数)/ 会话列表 / 帮助卡片 |
| 会话类 | /new /resume [序号|id] /stop /workspace <路径> |
新会话 / 极简恢复历史会话 / 停当前任务 / 切工作区 |
| 诊断 | /doctor |
ZIP 诊断包(session log + 配置 + ISSUE.md) |
| 热改 | /lark-config key=value |
热改配置(如 groupPolicy=open、agentPreset=standard、streaming.enabled=true) |
| DSH 命令 | /compact 等 |
原生执行,结果回飞书 |
| 多媒体 | 发图片/文件 | 图片→视觉模型;文件→文本提取 |
| 意图确认 | 模型提问 | 自动转飞书意图确认卡片,选项或输入作答 |
命令无拦截、无门禁:一切
/消息要么桥处理,要么原样交 DSH——绝不静默丢弃。skill 无前缀,直接说任务即可。
⚙️ 常用配置(/lark-config 热改,立即生效并持久化)
| 配置键 | 默认 | 说明 |
|---|---|---|
groupPolicy |
open |
群聊触发策略:open(免 @ 全触发)/ mention / keywords / reply |
groupKeywords |
["lark","bot"] |
keywords 模式下的触发词 |
agentPreset |
ptc |
Agent preset(shipped:standard/ptc/minimal/cordis,或 GUI 自建 id;历史别名 code 会自动映射为 ptc) |
permissionMode |
danger-full-access |
权限:read-only / workspace-write / danger-full-access |
streaming.enabled |
false |
CardKit 流式卡片(开=逐字打印) |
reactions.enabled |
true |
表情回执 |
allowlist |
[] |
open_id 白名单,空 = 所有人可对话 |
denyList |
[] |
命令前缀拒绝兜底 |
workspaceRoot |
`` | 桥会话工作区根目录(空 = process.cwd()) |
attachments.retentionHours |
168 |
入站图片/文件的保留时长(小时,默认 7 天;0 = 永久保留)。默认存系统临时目录,到期自动清扫 |
attachments.dir |
`` | 入站媒体根目录覆盖(空 = 系统 tmpdir;重启生效) |
凭据(appId/appSecret)存放在 DSH credentials 服务,不进配置文件;
/lark setup扫码自动写入。
🩺 遇到问题?
- 飞书发
/doctor,得到 ZIP 诊断包(完整 session log + 脱敏配置 + ISSUE.md 模板) - 把诊断包贴给任意 AI(或在 GitHub Issue 中发出来),即可快速定位
/status可随时看连接 / Outbox / 补发 / 会话全链路健康
🛠 开发者
npm run dev:link # 链接本地 DSH checkout(类型检查/测试需要)
npm run check # tsc --noEmit
npm test # 264 项单元 + 集成测试
npm run build # tsdown → dist/(宿主 ESM + client bundle)
npm pack # 产出可分发 tarball
架构:桥 = Cordis 插件(dsh.bundle 格式),分层清晰:
host(SDK 适配/认证)→ inbound(传输/群触发/断连补偿/Inbound WAL)→ application(命令路由/消息编排/诊断)→ outbound(Outbox/事件转发/卡片)→ sessions(每会话 Agent 管理)。
CI(GitHub Actions):push/PR 自动跑类型检查 + 264 项测试 + 构建;发布 npm 走 tag release 的 Publish workflow。
📄 许可
MIT — 自由使用、修改、分发。
本项目为社区插件,与 DeepSeek、飞书或 Lark 无隶属关系。
English
DeepSeek Harness × Feishu/Lark bridge — put your DSH agent inside Feishu. Scan a QR code and go live in 30 seconds; chat from anywhere. Plus fully local voice transcription and a play bar in the Web GUI.
🌟 Why dsh-lark-plus
- Zero setup friction: QR-scan app creation — no Open Platform fiddling, no callback URL, no public server
- Zero message loss: durable Outbox (outbound) + Inbound WAL — crashes, hot reloads, and dsh restarts all recover
- Zero learning curve: every toggle is a single-select card; native DSH commands (
/goal/compact…) just work - A real agent: full tool belt (bash / files / subagents / workflows) driven from Feishu
✨ Features
| Capability | Description |
|---|---|
| 🎯 One-click auth | /lark setup scans a QR to create the Feishu app (auto-subscribes message events + group-all + reactions). 30-second onboarding; manual DSH_LARK_APP_ID/SECRET channel also supported |
| 🧠 Multi-mode Agent | Standard / Code / Minimal / Cordis presets + your custom GUI presets; /mode shows a single-select card — tap to switch (default Code: multi-step tools in one shot) |
| 🎛 Permission tiers | Read-only / workspace-write / Full access; /permission card switches instantly (Full access by default) |
| 🎨 Card-based commands | /mode /permission /model are all single-select button cards — tap, no typing; models grouped by provider |
| 💬 Intent confirmation | Model questions (ask_user_question) land as Feishu intent-confirmation cards (option buttons + multi-select dropdown + custom text); answer and the agent resumes |
| 😊 Reaction receipts | Random "got it" reaction on inbound; DONE ✅ on completion (only Feishu-validated emojis) |
| 💪 Outbound zero-loss | Persistent Outbox (JSONL + at-least-once + idempotency + per-lane parallel + failure quarantine + periodic prune), resumes after kill/restart; bridge command replies ride the Outbox too |
| 🆕 Inbound request replay | If the agent dies / plugin reloads / dsh restarts MID-TURN, the interrupted user message is auto re-triggered on boot (no more silently dropped requests) — durable Inbound WAL + boot reconciliation + attempt/time caps; /status shows the pending-replay count |
| 🛡 Self-healing connection | Probe-driven controlled reconnect + QuotaGovernor circuit breaker (auto-unblocks and reconnects after the quota window) + missed-message compensation; auto-avoids proxy env |
| 🔀 3-tier command routing | Bridge commands → bridge; DSH commands → native; /goal, unknown /xxx, plain text → injected verbatim (no gates). Skills need no prefix — just describe the task |
| 📎 Inbound media | Feishu images → visual model (attachment-backed); files → bounded text extraction |
| 📤 Outbound media | Model sends local files/images via lark_plus_send_local_file (workspace whitelist + size/format checks) |
| 🩺 One-click diagnostics | /doctor → ZIP bundle (full DSH session log + sanitized config + ISSUE.md) back to the chat |
| ✍️ Markdown rendering | Replies auto-render as CardKit cards (headings/lists/code/tables); plain text stays plain |
| 🌊 Optional streaming | /lark-config streaming.enabled=true hot-enables CardKit schema 2.0 streaming cards (off by default, saves traffic) |
| 🆕 Goal-driven long tasks | /goal <objective> launches autonomous long-running task loops directly from Feishu; /goal pause / resume / clear manage execution via clean natural conversation |
| 🆕 Session management | /new opens a fresh session; /resume clean-restores a historical session (button/index/id-prefix, resolves true titles, fixes cross-restart session collision); /workspace <path> switches; per-session isolated configuration |
| 🖥 Reuses DSH Web GUI | Bridge agents are native DSH sessions; conversations auto-group under their workspace; the web panel shows live Outbox/replay counters |
| 👥 Access control | allowlist restricts inbound to specific open_ids; groupPolicy (open / mention / keywords / reply); denyList command-prefix deny |
| 🔓 Full access by default | Sandbox full access + never-ask approvals |
🚀 Quickstart
Prerequisites: Node.js ≥ 24 and DeepSeek Harness installed (npm i -g @deepseek-ai/dsh).
dsh plugin --profile web add dsh-lark-plus@latest --ignore-scripts
dsh web
/lark setup # scan QR (30s)
/lark start
Open Feishu, find your bot, send anything — reaction receipt + full reply = end-to-end. Group chats need no @-mention.
Install variants: local tarball (npm pack, then dsh plugin --profile web add ./dsh-lark-plus-<version>.tgz --ignore-scripts) or GitHub source (github:amlyczz/dsh-lark-plus, requires build approval). Upgrade with dsh plugin --profile web update dsh-lark-plus --latest --ignore-scripts.
Updating after each release
Don't rely on @latest: it resolves the mirror's dist-tags.latest label — npmmirror-style mirrors can serve a stale tag (version metadata synced, tag still pointing at an older release), so pnpm sees Already up to date even though a newer version exists. The tag is what the mirror says; the version number is what you say.
# 1. See the real version list, bypassing tags:
npm view dsh-lark-plus versions --registry https://registry.npmjs.org
# 2. Install by explicit version (most reliable):
dsh plugin --profile web add dsh-lark-plus@<new-version> --ignore-scripts
# 3. Or force the official registry with @latest:
dsh plugin --profile web add dsh-lark-plus@latest --ignore-scripts --registry https://registry.npmjs.org
Suspicious Already up to date? Run dsh plugin --profile web outdated first — if it also shows the old version, the mirror tag is stale; use an explicit version. Restart dsh web after installing.
⌨️ Commands (Feishu side)
- Selectors (single-select cards):
/mode/permission/model - Goals:
/goal [objective|pause|resume|clear](autonomous tasks / pause / resume / clear) - Status:
/status/sessions/help - Sessions:
/new/resume [index|id]/stop/workspace <path> - Diagnostics:
/doctor(ZIP with session log) - Hot reload:
/lark-config key=value - DSH commands run natively:
/compact… - Media: send images/files to the bot
- Intent confirmations auto-arrive as cards
⚙️ Configuration (/lark-config, hot-reloaded & persisted)
| Key | Default | Meaning |
|---|---|---|
groupPolicy |
open |
group trigger: open / mention / keywords / reply |
agentPreset |
ptc |
agent preset (standard/ptc/minimal/cordis or custom; legacy alias code maps to ptc) |
permissionMode |
danger-full-access |
read-only / workspace-write / danger-full-access |
streaming.enabled |
false |
CardKit streaming cards |
reactions.enabled |
true |
reaction receipts |
allowlist |
[] |
open_id allowlist (empty = everyone) |
denyList |
[] |
command-prefix deny |
workspaceRoot |
`` | workspace root for bridge sessions |
attachments.retentionHours |
168 |
retention (hours) for inbound images/files (default 7 days; 0 = keep forever). Stored under the OS temp dir and swept by age |
attachments.dir |
`` | inbound media root override (empty = OS tmpdir; applies after reload) |
Credentials (appId/appSecret) live in the DSH credentials service, never in config files.
🩺 Troubleshooting
Send /doctor in Feishu — you get a ZIP with the full session log, sanitized config, and an ISSUE.md template. Hand it to any AI (or open a GitHub Issue). /status shows live connection / Outbox / replay health.
🛠 Development
npm run dev:link && npm run check && npm test && npm run build
264 unit + integration tests. GitHub Actions CI runs typecheck + tests + build on every push/PR; npm publishing rides the release-tagged Publish workflow.
Architecture (Cordis plugin, dsh.bundle format):
host (SDK adapter/auth) → inbound (transport/group policy/compensation/Inbound WAL) → application (command routing/orchestration/diagnostics) → outbound (Outbox/event forwarding/cards) → sessions (per-chat agent management).
📄 License
MIT — free to use, modify, and distribute.
This is a community plugin, not affiliated with DeepSeek, Feishu, or Lark.
归属与许可
- 本项目基于
dsh-lark-link(MIT License,Copyright (c) 2026 dsh-lark-link contributors)二次开发,保留了原项目的全部版权与许可声明(见LICENSE)。 - 新增部分:本地离线语音转写链路(
src/voice/、消息链路的audio分支、本机转写路由)以及相应的测试。 - 语音引擎 SenseVoice 与运行时 sherpa-onnx 由各自作者以 Apache-2.0 许可发布;模型文件不随本仓库分发,首次使用时从官方发布页下载。
- 本仓库以 MIT License 发布,见 LICENSE。
